Mower Is Too Large To Fit On Lift Gate For Delivery
Must have a loading dock or fork lift @ delivery locale to unload
24HP/726cc Kawasaki FS730 V-Twin OHV 4-Cycle Engine
Lightweight design increases efficiency and improves fuel economy
Delivers the power required to tackle the thickest of them
V-twin cylinders reduce vibration for a smoother ride
Dual Hydro-Gear EZT-3100 Hydrostatic Drive System
Delivers responsive maneuverability and a smoother ride
Provides optimal torque and speeds up to 7.5 MPH
Highly durable with an oil reservoir and internal mesh filter
60-Inch, Fabricated (Welded) 3-Blade Mower Deck
Features Cub Cadet’s best-in-class Aeroforce Max cutting system
Extra-wide mower deck allows you to get more done in fewer passes
Optimizes airflow and suction for better bagging and cut quality
15 cut heights ranging from 1″-4.5″
Cleaner Storage
Features a deck washout port that facilitates mower deck clean-up
Keep your grass clippings in the yard where they should be!
Simply connect a hose, turn on the water, and rinse away
Automotive-Inspired Seat
Ergonomic, comfortable 24″ high-back seat with cushioned armrests
Includes a ball-bearing seat slide and seat isolators
Fully adjustable and optimized to reduce riders fatigue
Adjustable Lap Bars
Accommodates riders of all shapes and sizes
A Real Steel
Durable squared tubular steel frame design
Reduces chassis flex for a more even cut and increased stability
Corrosion protected with a Triple Guard Corrosion Defense System
Turf Master Tires
Large 20″ x 12″ tires provide excellent traction and a smoother ride
Distribute weight evenly – great for uneven surface types
Increased traction on slopes and in wet conditions
LED The Way
Features dual-LED headlights for unmatched visibility in low light
ENGINE
Engine Brand Kawasaki®
Engine Model FS Series
Engine Displacement 725cc
Engine Output 24 hp
Fuel Tank Capacity 3.5 gal.
Cylinders/Material Twin
Engine Start Key
Engine Oil Capacity 2.1 qts.
Lubrication Fully pressurized
Charging System 15 Amp Regulated
Governor Manual
Choke Separate choke and throttle
Air Filter Dual element
Oil Filter Yes
BATTERY
Battery 12V 230 cold crank amps
DRIVE SYSTEM
Forward Speed 7.5 MPH
Reverse Speed 3.5 MPH
Rear Axle 1″
Transmission Housing Cast Aluminum
Transmission Type Hydro-Gear ZT 3100
CUTTING DECK
Deck Cutting Width 60″
Cutting Modes Discharge/mulch/bagging
Deck Wash Included
Deck Material 11-gauge fabricated steel
Deck Attach/Removal Removable
Deck Engagement (PTO) Pull knob (electric)
Deck Construction Fabricated
Spindle Construction Sealed cast aluminum housing (Maintenance free)
Blade(s) 3
Deck Lift Foot pedal with Dial Adjust
Cutting Height Range 1” – 4.5”
Anti-Scalping 2 ball, 1 nose
Deck Positions 15 positions
CHASSIS
Frame 2” x 2” tubular steel frame
Front Axle Steel
Front Caster Mount Sealed ball bearings
Turning Radius 0″
Front Tires 11″x6″-5″
Rear Tires 20″x12″-10″
Tire Tread Turf Master/Multi Trac
Rear Tow Hitch Included
Corrosion Protection Triple Guard Corrosion Defense System
Yokes 5/16″ steel
CONTROLS
Brakes Lap bar integrated
Steering Control Lap Bars
Display Hour meter
COMFORT
